industrial robot

• X Stroke: 150mm – 800mm
• Y Stroke: 100mm – 400mm
• Max Payload (Y axis): 3Kg – 26Kg
• Maximum Speed (X-axis): 1200mm/sec – 1200mm/sec
• Maximum Speed (Y-axis): 1200mm/sec – 1200mm/sec

• X Stroke: 150mm – 3050mm
• Y Stroke: 50mm – 650mm
• Max Payload (Y axis): 4.5Kg – 40Kg
• Maximum Speed (X-axis): 720mm/sec – 1875mm/sec
• Maximum Speed (Y-axis): 720mm/sec – 1875mm/sec

• X Stroke: 250mm – 2050mm
• Y Stroke: 150mm – 1050mm
• Max Payload (Y axis): 19Kg – 50Kg
• Maximum Speed (X-axis): 1200mm/sec
• Maximum Speed (Y-axis): 1200mm/sec

• X Stroke: 150mm – 1250mm
• Y Stroke: 150mm – 650mm
• Max Payload (Y axis): 13Kg – 30Kg
• Maximum Speed (X-axis): 1200mm/sec
• Maximum Speed (Y-axis): 1200mm/sec

• X Stroke: 150mm – 1250mm
• Y Stroke: 150mm – 1050mm
• Max Payload (Y axis): 8Kg – 30Kg
• Maximum Speed (X-axis): 1200mm/sec
• Maximum Speed (Y-axis): 600mm/sec

• X Stroke: 150mm – 3050mm
• Z Stroke: 150mm – 550mm
• Max Payload (Z axis): 3Kg – 30Kg
• Maximum Speed (X-axis): 1200mm/sec – 1875 mm/sec
• Maximum Speed (Z-axis): 300mm/sec – 1200 mm/sec

• Hoding power control:30 to 100% (1% steps)
• Speed control:20 to 100% (1% steps)
• Acceleration control:1 to 100% (1% steps)
• Multipoint position control:10,000 max.
• Workpiece size judgment:0.01 mm units (by ZON signal)

• Hoding power control:30 to 100% (1% steps)
• Speed control:20 to 100% (1% steps)
• Acceleration control:1 to 100% (1% steps)
• Multipoint position control:10,000 max.
• Workpiece size judgment:0.01 mm units (by ZON signal)

• Hoding power control:30 to 100% (1% steps)
• Speed control:20 to 100% (1% steps)
• Acceleration control:1 to 100% (1% steps)
• Multipoint position control:10,000 max.
• Workpiece size judgment:0.01 mm units (by ZON signal)

• Hoding power control : 30 to 100% (1% steps)
• Speed contro l: 20 to 100% (1% steps)
• Acceleration control : 1 to 100% (1% steps)
• Multipoint position control : 10,000 max.
• Workpiece size judgment : 0.01 mm units (by ZON signal)

• Controllable robot : XY-X・FLIP-X・PHASER・YP-X
• Certification : CE
• Field networks : Ethernet/IP, Ethernet, EtherCAT, CC-Link, DeviceNet, PROFINET, PROFIBUS
• Operating method : Programming / Remote command / Operation using RS-232C communication
• Points : 30,000Points
• Origin search method : Absolute / Incremental / Semi-absolute

• Applicable robot : XY-X・YK-X・FLIP-X・PHASER・YP-X
• Certification：CE
• Field Networks :CC-Link, DeviceNet™, Ethernet/IP™, Ethernet, EtherCAT, PROFIBUS, PROFINET
• Operating method : Programming / Remote command / Operation using RS-232C communication
• Points：30000 points
• Input power supply : Single-phase 200 to 230V AC +/-10% maximum, 50/60Hz
• Origin search method : Absolute / Incremental / Semi-absolute

• The 6-axis robots range from the ultra-light YA-RJ with 1 kg payload up to the YAR6F with 6 kg payload and longest reach in class (1422mm).

• The 7-axis robots open up new possibilities due to the very high degree of motion like a human arm. It can reach behind objects and used in narrow space. Variations from 5 to 20 kg payload are available.

– A new model SCARA robot with thoroughly-redesigned mechanism and control functions.
– Suitable for assembly and inspection process of electronics equipment and automobile components where precision is required.
– Accurate movement trajectory. High speed operation and high load performance are achieved.
・Cycle time 0.39 second (with 2 kg load).
・Maximum payload 5 kg.
・Allowable moment of inertia 0.06 kgm²

– Suitable for the assembly and inspection process of electronics equipment and automobile components where precision is crucial.
– Accurate movement trajectory, high speed operation and high load capacity are achieved at the same time.
・Standard cycle time 0.3 seconds level (at 2 kg load)
・Maximum load 12 kg
・Allowable inertia moment 0.25 kgm².
– A new model SCARA robot with thoroughly redesigned mechanism and control functions.

-Suitable for the assembly and inspection process of electronics equipment and automobile components where precision is crucial.
– Accurate movement trajectory, high speed operation and high load capacity are achieved at the same time.
・Standard cycle time 0.4 seconds level（at 2 kg load）
・maximum load 20 kg
・Allowable inertia moment 0.6 kgm²
– A new model SCARA robot with thoroughly redesigned mechanism and control functions.

Small-size SCARA robot THL series with arm lengths of 300mm and 400mm.
These SCARA robots were developed under the concept of low cost, lightweight and energy saving.

They are SCARA robots with arm lengths of 500mm to 700mm.These SCARA robots were designed to be environmentally friendly and are available at reasonable prices.

Large-size SCARA robot THL series with arm lengths of 800, 900 and 1,000mm.
These SCARA robots were developed under the concept of low cost, lightweight and energy saving.

1,200mm arm length addition to the THL series.
Wider working envelope for greater productivity.

• Cleanroom Design
• Contributing automation, labor saving and productivity up Achieving insertion and copying operations without a force sensor

• Special feature: Tap holes, alternative installation, first arm equipped with a T-groove as standard
• Cabling can be routed though the base eliminates
  the need for installation space at the rear, and increases
  flexbility relating to the application and the space availble.

• Cleanroom Design
• Achieves high inertia and strong payload capabilities while at the same time the robot body has a reduced weight
• Contribute to efficiency, and cost and labor saving

• รับบรรทุกน้ำหนัก : 5kg
• รับบรรทุกน้ำหนักสูงสุด : 7kg
• ระยะยืดแขนที่หุ่นยนต์ทำได้ : 710mm
• มาตรฐานความปลอดภัย : CE/RoHS2.0

• รับบรรทุกน้ำหนัก : 5kg
• รับบรรทุกน้ำหนักสูงสุด : 7kg
• ระยะยืดแขนที่หุ่นยนต์ทำได้ : 710mm
• มาตรฐานความปลอดภัย : CE/RoHS2.0

• รับบรรทุกน้ำหนัก : 10kg
• รับบรรทุกน้ำหนักสูงสุด : 12kg
• ระยะยืดแขนที่หุ่นยนต์ทำได้ : 1476mm
• มาตรฐานความปลอดภัย : CE/RoHS2.0

• รับบรรทุกน้ำหนัก : 30kg
• รับบรรทุกน้ำหนักสูงสุด : 32kg
• ระยะยืดแขนที่หุ่นยนต์ทำได้ : 1151mm
• มาตรฐานความปลอดภัย : CE/RoHS2.0

• รับบรรทุกน้ำหนัก : 2kg
• รับบรรทุกน้ำหนักสูงสุด : 5kg
• ระยะยืดแขนที่หุ่นยนต์ทำได้ : 400mm

• รับบรรทุกน้ำหนัก : 5kg
• รับบรรทุกน้ำหนักสูงสุด : 10kg
• ระยะยืดแขนที่หุ่นยนต์ทำได้ : 700mm

• The RV-FR series offers a highly-dynamic 6-axis articulated robot for a high degree of quality. “Next-generation intelligent functions”, “Safe, collaborative work applications”, and “FA-IT integration functions”. With these 3 key features, the FR Series is capable of handling virtually all your automation needs.

• The F Series high capacity robots RV-35F/RV-50F/RV-70F with payload from 35 kg up to 70 kg are addressing applications that require higher payloads and longer reaches

• The RV-8CRL robot is perfect for pick and place, material handling and loading/unloading where the cost effective solution is needed. Thanks to the compact & functional design and wide operating range, the RV-8CRL robot would fit for several kind of applications.

• The RH-FR series allows for fast palletizing, targeted re-sort, perfect fit: and all of this in record time. “Next-generation intelligent functions”, “Safe, collaborative work applications”, and “FA-IT integration functions”. With these 3 key features, the FR Series is capable of handling virtually all your automation needs.

• The RH-CRH robots are suitable for a wide range of applications thanks to their compact design and large working area, offering a cost-effective scara solution.
